3rd Generation

Triple Synergy

Injector

SYNERJET PRO Skin Resurfacing

Courtesy of HIRONIC Clinical Team

Before

After

Treatment

Face

Protocol

1) Plasma

- MODE: Continuous
- 3 pass

2) EP Tip

- 10mm
- Power 150
- Hz 10
- Volume 2.0
- EP Level 2

SYNERJET PRO Skin Brightening (with PLASMA)

Courtesy of HIRONIC Clinical Team

Before

After

Treatment

Face

Protocol

1) Plasma

- MODE: Continuous
- 2 Pass
- POWER 3
- ON Time 0.5 sec
- Repetition 0.5 sec

2) EP Tip

- 10mm
- Power 150
- Hz 10
- Volume 2.0
- EP Level 2

SYNERJET PRO Skin Rejuvenation (with PLASMA)

Courtesy of HIRONIC Clinical Team

Before

After

Treatment

Face

Protocol

1) Plasma

- MODE Continuous
- 2 Pass
- POWER 3
- ON Time 0.5 sec
- Repetition 0.5 sec

2) EP Tip

- 15mm
- Power 170
- Hz 10
- Volume 2.7
- EP Level 2

SYNERJET PRO Skin Hydration (with PLASMA)

Courtesy of HIRONIC Clinical Team

Before

After

Treatment

Face

Protocol

1) Plasma

- MODE Continuous
- 2 Pass
- POWER 3
- ON Time 0.5 sec
- Repetition 0.5 sec

2) EP Tip

- 10mm
- Power 150
- Hz 10
- Volume 2.0
- EP Level 2

SYNERJET PRO Skin Resurfacing (with PLASMA)

Courtesy of HIRONIC Clinical Team

Before

After

Treatment

Face

Protocol

1) Plasma

- MODE Continuous
- 2 Pass
- POWER 3
- ON Time 0.5 sec
- Repetition 0.5 sec

2) EP Tip

- 10mm
- Power 150
- Hz 10
- Volume 2.0
- EP Level 2

SYNERJET PRO Skin Resurfacing

Courtesy of HIRONIC Clinical Team

Before

After

Treatment

Face

Protocol

1) Plasma

- MODE: Continuous
- 3 pass

2) EP Tip

- 10mm
- Power 150
- Hz 10
- Volume 2.0
- EP Level 2

SYNERJET PRO Skin Brightening (with PLASMA)

Courtesy of HIRONIC Clinical Team

Before

After

Treatment

Face

Protocol

1) Plasma

- MODE: Continuous
- 2 Pass
- POWER 3
- ON Time 0.5 sec
- Repetition 0.5 sec

2) EP Tip

- 10mm
- Power 150
- Hz 10
- Volume 2.0
- EP Level 2

SYNERJET PRO Skin Rejuvenation (with PLASMA)

Courtesy of HIRONIC Clinical Team

Before

After

Treatment

Face

Protocol

1) Plasma

- MODE Continuous
- 2 Pass
- POWER 3
- ON Time 0.5 sec
- Repetition 0.5 sec

2) EP Tip

- 15mm
- Power 170
- Hz 10
- Volume 2.7
- EP Level 2

SYNERJET PRO Skin Hydration (with PLASMA)

Courtesy of HIRONIC Clinical Team

Before

After

Treatment

Face

Protocol

1) Plasma

- MODE Continuous
- 2 Pass
- POWER 3
- ON Time 0.5 sec
- Repetition 0.5 sec

2) EP Tip

- 10mm
- Power 150
- Hz 10
- Volume 2.0
- EP Level 2

SYNERJET PRO Skin Resurfacing (with PLASMA)

Courtesy of HIRONIC Clinical Team

Before

After

Treatment

Face

Protocol

1) Plasma

- MODE Continuous
- 2 Pass
- POWER 3
- ON Time 0.5 sec
- Repetition 0.5 sec

2) EP Tip

- 10mm
- Power 150
- Hz 10
- Volume 2.0
- EP Level 2

more materials coming soon

SYNERJET PRO™ Clinical Study Report: Absorption

SYNERJET PRO™ Clinical Study Report: Hydration

SYNERJET PRO™ Physician's Guide

SYNERJET PRO™ Study Summary: Hydration

SYNERJET PRO™ Study Summary: Absorption

SYNERJET PRO™ User Manual

SYNERJET PRO™ Treatment Guide

SYNERJET PRO™ Simple Treatment Manual

SYNERJET PRO™ HANDPIECE (BRUSH TIP)

SYNERJET PRO™ HANDPIECE (PLASMA TIP)

SYNERJET PRO™ HANDPIECE (PLASMA)

SYNERJET PRO™ HANDPIECE TIP

SYNERJET PRO™ DEVICE(SIDE)

SYNERJET PRO™ DEVICE(FRONT)

SYNERJET PRO™ DEVICE(LEAFLET)

SYNERJET PRO™ HANDPIECE

SYNERJET PRO™ HANDPIECE

SYNERJET PRO™ LOGO

SYNERJET PRO™ Life-size standee

SYNERJET PRO™ BANNER

SYNERJET PRO™ Brochure: Global Version

SYNERJET PRO™ Brochure: Southeast Asia Exclusive

SYNERJET PRO™ Comparison to Other Solenoid Injectors

SYNERJET PRO™ Brochure

SYNERJET PRO™ Product Presentation

more materials coming soon

SYNERJET PRO™ Video Treatment Guide: Setting

A detailed walkthrough on preparing and configuring the SYNERJET PRO™ device, including setup, jet calibration, and safety checks for optimal performance

SYNERJET PRO™ Video Treatment Guide: Rejuvenation

A step-by-step visual guide demonstrating proper techniques, protocols, and best practices for using the SYNERJET PRO™ needle-free device effectively and safely.

SYNERJET PRO™ Key Expert Interview

An exclusive interview with Dr. Hong Wonkyu, sharing his expert insights on the SYNERJET PRO™ needle-free technology

SYNERJET PRO™ Device 3D Modelling

Explore the SYNERJET PRO™ in high-resolution 3D—see detailed visuals of the device, handpieces, and design features from every angle.

SYNERJET PRO™ Device 3D Modelling

Explore the SYNERJET PRO™ in high-resolution 3D—see detailed visuals of the device, handpieces, and design features from every angle.

SYNERJET PRO™ Video Treatment Guide: Setting

A detailed walkthrough on preparing and configuring the SYNERJET PRO™ device, including setup, jet calibration, and safety checks for optimal performance

SYNERJET PRO™ Video Treatment Guide: Rejuvenation

A step-by-step visual guide demonstrating proper techniques, protocols, and best practices for using the SYNERJET PRO™ needle-free device effectively and safely.

SYNERJET PRO™ Key Expert Interview

An exclusive interview with Dr. Hong Wonkyu, sharing his expert insights on the SYNERJET PRO™ needle-free technology

Q01. What is the certification status (MFDS, CE, FDA, etc.)?

- SJ is certified as a KC aesthetic device, and SP is currently under MFDS approval.

Q02. What is the difference between SJ and SP?

  • - SJ is classified as an aesthetic device, with a maximum of 20 Hz, and can only be used with cosmetic-grade products.
  • - SP is classified as a medical device, supports up to 25 Hz, and is compatible with medical-grade fillers and skin boosters.
  • Q03. What is the difference between EP Tip depth options?

    - 5 mm / 10 mm / 15 mm
    → Depth determines pain level and penetration strength.
    → Choose according to treatment intention and patient skin condition.

    Q04. What are the SJ/SP shot counts and lifespan?

  • - 9,000 shots per tip (single-use).
  • - Guaranteed performance up to 4,500 shots.
  • Q05 - When should the EP Tip be replaced, and how should it be cleaned?

  • - The EP Tip is made of PC material and is sensitive to high temperatures (over 80°C).
    → Alcohol disinfection is recommended.
  • - If biological residues or blood are present, ultrasonic cleaning is recommended.
  • - Replacement is recommended every 5–10 patients per tip.
  • Q06 - What are Synerjet’s main differentiating points?

    Compared with conventional needle injections or injector devices, SynerJet offers:

    • Less pain
    • Uniform and precise delivery
    • Shorter treatment time
    • Accurate delivery into the upper & papillary dermis
    • Lower risk of complications
    • Subcision-like effect

    Q07 - What is the difference compared to Mirajet?

    • Mirajet: Micro-jet delivery powered by laser energy
    • SynerJet: Solenoid-based jet injection

    Both deliver substances needle-free. However, Mirajet uses laser pressure, while SynerJet uses high-pressure solenoid propulsion.

    Mirajet claims faster injection and recovery but has weaker power, resulting in high product loss and low clinical effect. Several clinicians reported selling it due to inconsistent results.

    SynerJet provides:

    • Adjustable pressure
    • EP Tip with electroporation → minimizes product loss
    • Plasma tip → creates temporary channels → improves absorption by up to 45% compared to Mirajet

    Q8 - What is the difference compared to CureJet?

    CureJet only has one subcision-dedicated handpiece, limiting its ability for rejuvenation or drug delivery. Product loss is relatively high.

    SynerJet provides:

    • A dedicated subcision handpiece
    • EP Tip for minimal product loss
    • Plasma handpiece for temporary channel opening
      → Up to 45% higher absorption compared to CureJet
    Q09 - What is the recommended treatment interval?

  • - Varies by patient condition, but typically every 2–4 weeks.
  • - Repeated treatment (3+ sessions) enhances results.
  • Q10 - What are the benefits of combining Plasma with SynerJet?

  • - Maximized absorption: Micro-jet + electroporation + plasma enhances the delivery of active ingredients.
  • - Surface preparation & sanitation: Plasma smooths the surface and provides mild sterilization.
  • - Multi-effect synergy: Improved wrinkles, pigmentation, hydration, etc.
  • - Reduced pain & downtime: Plasma reduces irritation and promotes faster healing.
  • Q11 - What is the treatment duration?

  • - SynerJet: 5–15 minutes
  • - Manual needle injection: 20–30 minutes
  • Q12 - Which cosmetic boosters and skin boosters are compatible?

  • - PLLA products (e.g., Juvelook)
  • - PCL products (e.g., Gouri)
  • - Exosome boosters
  • - Botulinum toxin (micro-botox)
    (Usage depends on regulatory classification in each country)
  • Q13 - What are the dilution ratios and methods?

    PLLA (e.g., Juvelook)

    • 1 vial (150 mg) + 5 mL Sterile Water
    • Reconstitute for 2+ hours (ideally overnight)
    • Optional: add 1–1.5 mL lidocaine
    • Mix thoroughly before use
    • Recommended dilution: 5–6.5 mL total volume

    Juvelook Skin (Example):

    • Juvelook Skin 50 mg + 10 mL N/S
    • After 24-hour hydration + vortex mixing →
      Use 1 cc Juvelook : 2 cc N/S ratio

    Gouri:

    • Dilution: 1 : 4 (Gouri : N/S)
    • Full face: approx. 2.5 cc

    Important notes:

    • All boosters and botulinum toxin must be refrigerated after hydration.
    • If viscosity is too high, increase N/S ratio.
    • Ratios of lidocaine, HA, and N/S may be adjusted based on physician preference.

    Q14 - What is the treatment pricing?

    - Pricing varies greatly by clinic.Since this is not a national insurance procedure, cost depends on clinic, region, drug type, and treatment plan.Generally, procedures using CureJet or similar devices range from 200,000–500,000 KRW per session, but premium boosters or large-area treatments may cost more.

    Q15 - What is the Jet pressure and speed?

  • - Maximum jet velocity: ~580 m/s
  • - Nozzle diameter: ~180 μm
  • - High-pressure micro-jet allows uniform and deep delivery
  • - Optimized for skin regeneration and maximal absorption efficiency
